Unitronics
Snap IOs
- Plugs directly into the back of compatible Unitronics OPLC
- Creating a self contained PLC unit
- Range of I/O modules ensures flexible configuration
Unitronics Snap IO plugs directly on the back of compatible OPLCs
| Snap-in I/O | Summary |
| V200-18-E1B | 16 Digital Inputs including 2 HSC, 3 Analog Inputs, 10 Relay Outputs, 4 Outputs (pnp/npn) including 2 HSO |
| V200-18-E2B | 16 Digital Inputs, 2HSC(pnp/npn), 2 Analog Inputs, 10 Relay Outputs, 2 HS Outputs, 2 Analog Outputs |
| V200-18-E3XB | 18 Digital Includes 2 HSC, 4 Analog/PT100/TC Inputs, 15 Relay Outputs, 2(PNP/NPN) Uutputs, includes 2 H.S, 4 Analog outputs |
| V200-18-E4XB | 18 Digital Includes 2 HSC, 4 Analog/PT100/TC Inputs, 15 Transistor Outputs, 2(PNP/NPN) Uutputs, includes 2 H.S, 4 Analog outputs |
| V200-18-E5B | 18 Digital Inputs, 2 HSC(pnp/npn), 3 Analog Inputs 15 Outputs (pnp), 2 HS Outputs |
| V200-18-E6B | 18 Digital Inputs(pnp/npn), 2 shaft encoder inputs, 5 Analog Inputs, Includes 2 configurable to RTD/TC, 15 Relay Outputs, 2 (pnp/npn) Outputs / 2 high-speed outputs, 2 Analog Outputs. |
| V200-18-E46B | 18 Digital, includes 2 H.S.C Inputs, 4 Analog/PT100/TC inputs, 15 pnp Outputs, 2 pnp/npn Outputs, includes 2 H.S. outputs, 4 Analog outputs |
| V200-18-E62B | 30 Digital Inputs, includes 2 shaft encoder inputs, 2 Analog Inputs, 28 Outputs (pnp), 2 Outputs(pnp/npn) includes 2 high-speed outputs |
Technical Specifications
Mechanical
| General Features | Back panel fit for V570/V700/V1040/V1210 |
| Operating Temperature | 0 … 50 °C |
| Dimensions | 138x23x123mm (5.43x0.9x4.84”) |
| Installation options | Mount onto back of V570/700/1040/1210 |
Electrical
| IO Options | digital &/ analog &/ high speed, temperature &/ weight measurement |
| Supply Voltage | 24 VDC |
