Grid scan/Mini-SB2-ST2
- TÜV – EC Type examination certified
- Fulfills ASR A1.7
- SIL 2 certified
- FSS version fulfills SIL 2 without testing
- Direct integration into the door edge (SB2 type)
- Door speeds up to 1.6 m/s
- Waterproof housing (IP67)
Description
CEDES Extremely Compact Safety Light Curtains : Used for applications like High-speed doors, Sectional doors, Rolling doors, Vertical closing telescopic doors
Technical Specifications
Mechanical
| Cross-section | 12 mm × 16 mm |
| RoHS | 2011/65/EU |
| Enclosure rating | IP67 |
Electrical
| Operating range | 1.2 ... 8 m |
| Supply voltage USP | 10 ... 30 VDC |
