5873
Kübler

Kübler 5873

Genuine Kübler product, supplied in India by Rajdeep Automation, the authorised Kübler distributor.

  • High precision
  • Resistant
  • Reliable
  • Dimension Ø 58 mm
  • 2.048 ppr incremental
  • 21 bits singleturn
  • Max 15 mm hollow shaft, through
  • Max 3/8" hollow shaft, through
  • Max 1/2" hollow shaft, blind hole
Not sure this is the right model? Read the rotary encoders selection guide →

Kuebler : For drive technology. Encoders with additional incremental track ,the absolute encoders Singleturn Sendix 5853 / 5873 with SSI or BiSS interface and optical sensor technology achieve a resolution of max. 21 bits.These encoders are also available with an additional incremental track. Special design for attachment to direct drives in elevator technology.

Technical Specifications

Mechanical

DimensionØ 58 mm
Shaft type10 mm hollow shaft, through 12 mm hollow shaft, through 14 mm hollow shaft, through 15 mm hollow shaft, through 3/8 " hollow shaft, through 1/2 " hollow shaft, blind hole
Flange typeØ 58.00 mm Ø 63.00 mm Ø 65.00 mm Ø 72.00 mm
Connection typesAxial cable Radial cable Tangential cable M23 connector radial M12 connector radial
Max. rotational speed9.000 min-1

Electrical

Working temperature-40 °C ... +90 °C
Power supply5 V DC 10...30 V DC
InterfacesSSI, binär SSI, gray SSI + 2048 ppr SinCos SSI + 2048 ppr RS422 BiSS BiSS + 2048 ppr SinCos BiSS + 2048 ppr RS422
Resolution max2.048 ppr incremental 21 bits singleturn

Applications

  • Absolute position feedback on direct drives in elevator systems
  • Servo motor feedback in drive technology with SSI or BiSS
  • High-resolution angle measurement on rotary tables and indexers
  • Position feedback on robotic and handling axes
  • Speed and position feedback on packaging and printing machines
